Usage:
Ignition protected, used for Cars, RV, yachts, trucks, Marine boat
Function:
Switches a single battery to a single load group
Operation:
Turn all appliances off before turning the battery switch to OFF; don’t switch to OFF when engine is running
Product Information
Usage: ignition protected, used for Cars, RV, yachts, trucks, Marine boat
Function: Switches a single battery to a single load group
Operation: turn all appliances off before turning the battery switch to OFF; don’t switch to OFF when engine is running
Technical Parameters
| Model | ZYBS-6006 |
| Brand | ZOYSEAY |
| Color | RED or BLACK |
| Switch Position | 2 |
| Terminal Stud Torque | 120 in-lb (13.56 Nm) |
| Continues Rating | DC 300A |
| Intermittent Rating | DC 500A (5min.) |
| Cranking Rating | DC 900A (30sec.) |
| Maximum Voltage | DC 48V |
| Cable size | 4/0AWG |
| Ingress protection | IP66 |
| Weight | 365g |
| Materials | ABS COVER, 304SS SCREW |
Technical Parameters
| 6006 | 6007 | 6008 | 6010 | 6011 | |
| Switch Type | Single circuit on -off | Selector 4 position | Selector3 position | Dural Circuit | Dural Circuit plus |
| Battery combine | yes | no | yes | no | |
| Rating | 300A (continuous) 500A (intermittent 5min.) 900A (cranking 30sec.) | 300A (continuous) 500A (intermittent 5min.) 900A (cranking 30sec.) | 300A (continuous) 500A (intermittent 5min.) 900A (cranking 30sec.) | 300A (continuous) 500A (intermittent 5min.) 675A (cranking 30sec.) | 300A (continuous) 500A (intermittent 5min.) 675A (cranking 30sec.) |
| Maximum voltage | 48VDC | 32VDC | 32VDC | 32VDC | 32VDC |
